Post your turbo / supercharged setup

Discussion regarding Turbocharged and supercharged MX-5s

Moderators: timk, Stu, -alex, StanTheMan, greenMachine, ManiacLachy, Daffy, zombie, The American, Lokiel, Sean

Post Reply
User avatar
bootz
Racing Driver
Posts: 891
Joined: Thu Aug 19, 2010 1:13 pm
Vehicle: NB8B
Location: The Wild Wild West

Re: Post your turbo / supercharged setup

Postby bootz » Sat Jun 15, 2013 6:03 pm

NitroDann wrote:A bit of boost control bounce but yes it's very clean.


Dann


What shows that, the wiggles at the start of the torque plateau?

All I know about dyno sheets is that this one has a nice fat kw figure for an NB turbo. It is also has a nice flat power curve and a flat torque curve. I would like to see the Air/Fuel ratio readout as well.
Bootz and Boof - On the road to somewhere.
Top
User avatar
NitroDann
Forum sponsor
Posts: 10280
Joined: Thu Nov 05, 2009 12:10 pm
Vehicle: NA6
Location: Newcastle NSW
Contact:
Contact NitroDann

Re: Post your turbo / supercharged setup

Postby NitroDann » Sat Jun 15, 2013 6:49 pm

The bottom graph is a boost pressure graph.

Dann
http://www.NitroDann.com

speed wrote:If I was to do it again, I wouldn't even consider the supercharger.
Top
User avatar
bootz
Racing Driver
Posts: 891
Joined: Thu Aug 19, 2010 1:13 pm
Vehicle: NB8B
Location: The Wild Wild West

Re: Post your turbo / supercharged setup

Postby bootz » Mon Jun 17, 2013 8:25 pm

NitroDann wrote:The bottom graph is a boost pressure graph.

Dann


Yep, I know bugger all about dyno charts and about the same for turbos.
Bootz and Boof - On the road to somewhere.
Top
User avatar
Okibi
Speed Racer
Posts: 10904
Joined: Thu Aug 21, 2003 11:00 am
Vehicle: NB SE
Location: Perth, Western Australia
Contact:
Contact Okibi

Re: Post your turbo / supercharged setup

Postby Okibi » Tue Jun 18, 2013 1:38 am

Here's one of Simon's SE.

If you had access to a car like this, would you take it back right away? Neither would I.
Top
User avatar
Rorge
Fast Driver
Posts: 100
Joined: Mon Aug 25, 2008 12:29 am
Vehicle: NA6 - Turbo

Re: Post your turbo / supercharged setup

Postby Rorge » Sat Jun 22, 2013 12:06 am

I made a new dump for my NA6-T28 setup which came out ok, did some hillclimbs with worn out RSR's..
https://www.facebook.com/video/embed?vi ... 8517852587

Then broke a couple of gears in one of many 5 speeds, fitted a 6speed and finally got a fresh tune from a mate in Sydney who's pretty good with Haltechs..(running an E8) It's running a 4.11 torsen so it's very short with the 6speed! 3500rpm @ 100km/h in 6th.
Engine bay with old 2.5" dump..

Dump
2 hours later with a hammer and using my Triton Superjaws as a vice and dolly I got this result..

Tune was on pump fuel and 550cc RX7 Injectors. (i'll switch to ID1000's when Ethanol is more readily on the pump. For now the car drives very smooth but lumpy idle 1000-1100rpm as the injectors don't appear to be able to pulse close enough together. It drives GREAT other than the wheelspin in 3rd if i'm a little hamfisted...
Top
User avatar
NitroDann
Forum sponsor
Posts: 10280
Joined: Thu Nov 05, 2009 12:10 pm
Vehicle: NA6
Location: Newcastle NSW
Contact:
Contact NitroDann

Re: Post your turbo / supercharged setup

Postby NitroDann » Sat Jun 22, 2013 12:17 am

Awesome job, looks like a downpipe or 2 I made before :P

Its hard work to cold work that flange shape isnt it !

Dann
http://www.NitroDann.com

speed wrote:If I was to do it again, I wouldn't even consider the supercharger.
Top
User avatar
Rorge
Fast Driver
Posts: 100
Joined: Mon Aug 25, 2008 12:29 am
Vehicle: NA6 - Turbo

Re: Post your turbo / supercharged setup

Postby Rorge » Sat Jun 22, 2013 1:20 am

It was tricky but kinda like meditation! I love making stuff! (i'm just really crap at it) That's why I built this home-made $hitbox! :)

The exhaust manifold looks alot 'tidier' than that after I chopped off the whole base of the merge/flange and used some new thick wall pipe to make it stronger/cleaner.
Top
User avatar
PaulF
Racing Driver
Posts: 1821
Joined: Fri Jan 28, 2011 5:55 pm
Vehicle: NA6
Location: Newcastle, NSW

Re: Post your turbo / supercharged setup

Postby PaulF » Sat Jun 22, 2013 4:38 am

Facebook video link doesn't work for me; do you have it set to public?
Top
lazy330
Driver
Posts: 41
Joined: Fri Oct 19, 2012 4:26 pm
Vehicle: NA6 - Turbo
Location: Sydney

Re: Post your turbo / supercharged setup

Postby lazy330 » Tue Sep 10, 2013 10:47 pm

Can't take any credit for it as I bought it this way, but here's mine. Completely impractical, but heaps of fun.

Top
User avatar
NitroDann
Forum sponsor
Posts: 10280
Joined: Thu Nov 05, 2009 12:10 pm
Vehicle: NA6
Location: Newcastle NSW
Contact:
Contact NitroDann

Re: Post your turbo / supercharged setup

Postby NitroDann » Tue Sep 10, 2013 10:56 pm

Looks like one of Suli's pieces of automotive art ? :)

Dann
http://www.NitroDann.com

speed wrote:If I was to do it again, I wouldn't even consider the supercharger.
Top
lazy330
Driver
Posts: 41
Joined: Fri Oct 19, 2012 4:26 pm
Vehicle: NA6 - Turbo
Location: Sydney

Re: Post your turbo / supercharged setup

Postby lazy330 » Tue Sep 10, 2013 11:08 pm

No. Was actually built in Rockhampton.

Joe
Top
User avatar
NitroDann
Forum sponsor
Posts: 10280
Joined: Thu Nov 05, 2009 12:10 pm
Vehicle: NA6
Location: Newcastle NSW
Contact:
Contact NitroDann

Re: Post your turbo / supercharged setup

Postby NitroDann » Tue Sep 10, 2013 11:09 pm

Awesome either way, thats a HUGE turbo especially on a 1,6.

What power does it make, on what boost?

Its a 3071 or similar?

Dann
http://www.NitroDann.com

speed wrote:If I was to do it again, I wouldn't even consider the supercharger.
Top
lazy330
Driver
Posts: 41
Joined: Fri Oct 19, 2012 4:26 pm
Vehicle: NA6 - Turbo
Location: Sydney

Re: Post your turbo / supercharged setup

Postby lazy330 » Tue Sep 10, 2013 11:48 pm

Dann,

PM Sent.

Joe
Top
User avatar
Okibi
Speed Racer
Posts: 10904
Joined: Thu Aug 21, 2003 11:00 am
Vehicle: NB SE
Location: Perth, Western Australia
Contact:
Contact Okibi

Re: Post your turbo / supercharged setup

Postby Okibi » Wed Sep 11, 2013 1:42 am

Love that intake manifold.
If you had access to a car like this, would you take it back right away? Neither would I.
Top
elitee
Fast Driver
Posts: 210
Joined: Sat Feb 19, 2011 7:26 pm

Re: Post your turbo / supercharged setup

Postby elitee » Wed Oct 09, 2013 9:56 am

new setup, still need to tidy it up a bit more and get a tune
